Disposable ESD Heel Strap

For visitors and temporary staff, this heel strap option is a simple low-cost alternative. Any heel strap needs to work in conjunction with an ESD static-controlled floor. Supplied in packs of 100 and easy to apply.
How to apply:
Firstly, position the main pressure-sensitive end of the heel strap strip with the front edge and centre of the shoe heel.
Then peel the protective liner and press it firmly to the bottom of the heel. Wrap the contact ribbon of the heel grounder up the back of the shoe and lay it inside. Place the foot in the shoe making contact with the heel grounder and then repeat the process with the other shoe.

Disposable ESD Heel Strap

Item No.: SHS3004

Made from 99% polyester, 1% conductive yarn

Comfortable to wear

Reliable static decay

Recommended for both shoes

Length: 30cm

Surface resistance: 104-6ohms

Compliant according to IEC-61340-1-5 International ESD Standard

Supplied as 10 heel straps per sheet and 10 sheets per pack
