ESD Jacket

ESD Jacket contain a quantity of static charge and do not allow any moment's static electricity to occur, thereby negatively affecting electronic parts. The use of ESD smocks and some other protective ESD clothes reduces RPE more likely than without clothes, thus protecting a product and a worker.
Notice:
1.Machine washable up to 40℃
2.Do not bleach
3.Do not use acid or alkali
4.Ironing at Medium temperature
5.Tumble dry at low temperature

ESD Jacket and Trousers

1)98% polyester+2% conductive fiber--- Grid Garment
99% polyester+1% conductive fiber---Strip Garment
35% cotton+63% polyester+2% conductive fiber
2) Yarn: 100D*100D
3) Gram weight: 125g
4) Wrap density: 68/cm
5) Colors available: white, green, light blue, royal blue, light grey and etc
6) Surface resistance: 10e6-10e8 Ohm or 10e7-10e9 Ohm
7) Permeability to air: 75cm3/cn2/sec
8) Static voltage: 23v
9) Friction voltage: 110v
10) Electrified capacity: 0.35μC/m2
11) Static decay: <0.4s
12) Durability: 50 washings
13) Customization is available
