ESD Shielding Rolls

The kind of bag can keep static-sensitive components away from the potential static danger to the largest extent. Its special four -layer structure can create such effect as an inductive cover to separate the goods inside from the static field.
Furthermore, the inner layer is made from ethane which can remove the static and avoid static generation inside the bag
In addition, this kind of hot seal bag is transparent, so the goods inside can be easily recognized from outside. And the surface resistance: 108-1011
Applicable to pack electronic products which are sensitive to static, such as PC board, IC integrated circuit ,CD driver, HD

Anti-static Shielding Rolls

Item No.: SSR0015

1. ESD Shielding Bags prevents products from damagesdue to static
2. Best choice for packing electronic products
3. All sizes are available in  open top/zip lock/self-adhesive/gusset/cubic styles

4.Material structure: metalized dissipative polyester outer layer/aluminum shielding layer/static dissipative polyethylene or polypropylene inner layer

NO.

Item

Unit

Test standard and result

1

Metal layer resistance

Ohm/sq

<100

2

Metal layer optical transmission

Optical density

40%-70%

3

Surface resistivity

Ohm/sq

108-1011

4

Time for static removal

5000-0V

<0.02 sec FTMS 101 B Method 4046

5

Puncture resistance

P.S.I

ASTM  D3420       >12 lbs,50N

7

MVTR

gm/100in-2/24hrs

ASTM  E  96      <0.3

8

Heat sealing Time

S

0.5-3.5 seconds

9

Hot sealing temperature

F

250-375F

10

Seal strength

N/15mm

ASTM D-882-91   ≥12 lbs/inch
