Model NO.: SMR0606

A PCB Magazine or PCB Rack is made of volume conductive polypropylene and metal, which is used to transport the PCB boards for automated assembly lines. The anti-static PCB magazines racks are an ideal aid in the production, storage and transportation of PCBs. The strong and robust sidewall and metal frame guarantee that these PCB magazines racks are durable, which last very long time.
• Gear adjustment
1.Anti-static plate independent R&D anti-static raw materials to ensure the service life of the products. Permanent anti-static function and stable electrostatic index around 104-108ohms
2.Anti-static side panel has high flatness, PCB will not be stuck
3.Anti-static magazine rack is upgraded to a quick adjustment mode, which is convent for customers to use and improve production efficiency
4.Spring stopper: prevent PCG from falling off, easy to use, will not shake
5.The bottom plate mold is integrally formed, scientifically designed to ensure straightness, and the machine is not stuck
6.Different temperature resistance: 80, 120, 200degrees convenient for customers to choice the suitable one
